Swisspearl REFLEX

Unique iridescent surface… through-bodied colors!

The various color families allow the unique character of the Swisspearl panels to be expressed in almost endless diversity.  The carefully chosen fully-body color and color finishes, each in their own way, emphasize the unmistakable aesthetics of the material and combine material and color to form a timeless material for modern rainscreen design.

The Swisspearl REFLEX collection furthers that endeavor by providing high-tech panels with an iridescent surface on a pure acrylic base.  These panels are directional and changing light and/or viewing angle produces fascinating nuances in the colors!  The directional panels come in 11 shades and are especially well-suited for modern architecture and contemporary buildings of any size or scope.

REFLEX panels are air-cured and not autoclaved (unlike competing panel products). Advantages of this approach include:

  • The 28-day curing process allows panels and fibers to cure naturally, without excess energy or heat applied
  • High-quality raw materials provide a better finish when air-cured over time
  • Longer lasting durability with increased 'creep' capacity - reduces tensile stresses from panel expansion/contraction
  • Natural process, no additional heat applied
  • Low moisture movement within panels, reducing internal panel stress
  • Better resistance to environmental/chemical agents based on air-cured process

Download the Swisspearl REFLEX Color Overview

Swisspearl REFLEX Series

Product Sizes

Product Sizes

Cladding Corp Largo Size 5/16“ Thick

Largo 8mm

120 1/16“ × 49 3/16“       5/16“

98 13/16“ × 49 3/16“      5/16“

Cladding Corp Largo Panel Size 1/2“ Thick

Largo 12mm

120 1/16“ × 49 3/16“      1/2“

98 13/16“ × 49 3/16“      1/2“

Cladding Corp Linearis 6 Thumbnail

Linearis 6

5 5/8” x 9’ 11 11/16”     5/16”

5 5/8” x 7’ 11 11/16”     5/16”

Cladding Corp Linearis 12 Thumbnail

Linearis 12

11 5/8” x 9’ 11 11/16”     5/16"

11 5/8” x 7’ 11 11/16”     5/16"

Cladding Corp Linearis 16 Thumbnail

Linearis 16

15 5/8” x 9’ 11 11/16”     5/16"

15 5/8” x 7’ 11 11/16”     5/16"

Cladding Corp Linearis 24 Thumbnail

Linearis 24

23 5/8” x 9’ 11 11/16”     5/16"

23 5/8” x 7’ 11 11/16”     5/16"

Color Palette

Anthracite 4021

Anthracite 4021

Anthracite 4022

Anthracite 4022

Jade 4051

Jade 4051

Coral 4031

Coral 4031

Amber 4072

Amber 4072

Amber 4071

Amber 4071

Ivory 4092

Ivory 4092

Ivory 4091

Ivory 4091

Crystal 4111

Crystal 4111

Crystal 4112

Crystal 4112

Granite 4161

Granite 4161

Granite 4162

Granite 4162

Project References

The project references highlighted in the below portfolio illustrate the breadth of our rainscreen experience and may not be associated with any of our current material suppliers.

Eco Cladding Attachment Systems

Alpha Hci.10 System

ALPHA HCI.10 SYSTEM

Panel Sub-framing system that offers visible rivet fixing for fiber cement panels. Rivet attachment guarantees high pull-out values and ease of installation. Engineered to address deadload, windload, seismic concerns, thermal requirements and material deflection for either steel stud or concrete back-up conditions.

Alpha Vci.10 Rainscreen Aluminum Sub-framing System

ALPHA VCI.10 SYSTEM

Panel Subframing system that offers visible rivet fixing for fiber cement panels. Rivet attachment guarantees high pull-out values and ease of installation. Engineered to address deadload, windload, seismic concerns, thermal requirements and material deflection for either steel stud or concrete back-up conditions.

Alpha Vci.40 Rainscreen Aluminum Sub-framing System

ALPHA VCI.40 SYSTEM

Panel Subframing system that offers fixing using concealed, undercut anchors for fiber cement panels. The back of each panel is pre-drilled using undercut drill bit to receive the hanger clip and expanding bolt anchor.
